FRAME

T-Tronik FX-Type Pro carbon sizes: 40, 44, 48, 52 - 12x148 mm thru axle dropouts - Post mount 180 disc brake type - 150mm travel front & rear - Internal cable routing in DT

FORK

RockShox YARI RC 29", 150mm travel, 1.5 tapered HT, Maxle Stealth 15x110mm BOOST axle, minimum 180mm rotor, maximum 220mm rotor, 42mm rake, 59mm crown

REARSHOCK

Fox Float DPS Performance, LV, EVOL, 3 position Lever

HEADSET

FSA NO.77R 1.5"

DRIVETRAIN

SHIFTERS

Shimano Deore SL-M6100, 12sp

REAR DERAILLEUR

Shimano Deore XT RD-M8100, 12sp

CRANKSET

Shimano FC-EM600, 165MM Shimano Chainring SM-CRE80-12-B, 34T

CHAIN

Shimano, CN-M6100

BRAKES

BRAKES

Shimano, BL-M6100, BR-M6120, 4 pistons

ROTOR

Shimano SM-RT64, RT-EM600, L 203MM

WHEELS

WHEELS

Velomann 29", 622x30, 32 hole

REARHUB

Shimano FH-MT510-B, for Center Lock, 32h, 12x148 TA

FRONTHUB

Formula CL-811 for Center Lock, 32h 15x110mm TA

TIRE

Kenda Hellkat 29x2.6, 60tpi, 66-622

COCKPIT

STEM

Velomann +/-0°, 1,1/8 x diam.35mm, 50mm

HANDLEBAR

Velomann width 780mm, diam.35mm, rise 20mm, backsweep 9°

GRIPS

T-One Rock T-GP34

SADDLE

SEATPOST

JD, diam.31,6mm, internal remote cable routing 100m travel --> size 40 125m travel --> size 44 150m travel --> sizes 48, 52

SADDLE

Fizik Alpaca Terra, S alloy rail, 249x145
